NEW FOR 2022

Trijicon Bolt Action Mount w/ Trijicon Q-LOC™ Technology

Fits 30mm Tubes, Height Above Rail: 1.125 in.

OVERVIEW

Triicon's Bolt Action Mount w/ Trijicon Q-LOC™ Technology is designed to keep the optic as low as possible for hunting and long range precision rifle applications. Featuring a Mil-Spec drop test rated 6061-T6 aluminum design, and an easy to use one handed toolless mounting system. The spring-loaded design allows for constant retention and maintaining of zero even if the knobs are not tightened.

This mount boasts a low weight and low profile design with precise return to zero performance and is compatible with any Mil-Spec or NATO Picatinny rail.

Designed specifically for variable powered optics, this lightweight mount is perfect for mounting Trijicon variable powered tube riflescopes with an objective lens up to 56mm on any firearm platform with a picatinny rail.

• Matte Black Anodized Finish
• Made in the USA

Distance From Top of Mounting Rail to Optical Axis:
1.125 in.

Torque Spec (to Rail):

Spring Tension Only: 12-16 in. / lbs
Can be Tightened To:  44-66 in. / lbs

Torque Spec (Ring Caps):

14-16 in. / lbs

NOTE: Fits Objective lens up to 56mm

reticle image

INCLUDES

    1 Mount
    2 Ring Caps
    8 Screws
    1 Hex Key

SKU: AC22044

RETAIL: $350.00

FIND A DEALER

Triicon's Bolt Action Mount w/ Trijicon Q-LOC™ Technology is designed to keep the optic as low as possible for hunting and long range precision rifle applications. Featuring a Mil-Spec drop test rated 6061-T6 aluminum design, and an easy to use one handed toolless mounting system. The spring-loaded design allows for constant retention and maintaining of zero even if the knobs are not tightened.

This mount boasts a low weight and low profile design with precise return to zero performance and is compatible with any Mil-Spec or NATO Picatinny rail.

Designed specifically for variable powered optics, this lightweight mount is perfect for mounting Trijicon variable powered tube riflescopes with an objective lens up to 56mm on any firearm platform with a picatinny rail.

• Matte Black Anodized Finish
• Made in the USA

Distance From Top of Mounting Rail to Optical Axis:
1.125 in.

Torque Spec (to Rail):

Spring Tension Only: 12-16 in. / lbs
Can be Tightened To:  44-66 in. / lbs

Torque Spec (Ring Caps):

14-16 in. / lbs

NOTE: Fits Objective lens up to 56mm

QUICK-RELEASE, RETURN-TO-ZERO

QUICK-RELEASE, RETURN-TO-ZERO

Multiple proprietary recoil lugs ensure total rail engagement. Easily remove and re-attach without needing to confirm zero.

AUTOMATIC RETENTION KEEPS OPTIC SECURE

AUTOMATIC RETENTION KEEPS OPTIC SECURE

Heavy-duty springs ensure secure retention under heavy, repeated recoil. Facilitates one-handed mounting.

SNAG-RESISTANT KNOB DESIGN

SNAG-RESISTANT KNOB DESIGN

Compact, circular design minimizes hazards of gear snags.

PRECISION-CUT DIMENSIONS

PRECISION-CUT DIMENSIONS

Ensures optimal placement on MIL-STD 1913, NATO, non-mil spec, and even damaged rails.

PROVEN DURABILITY

PROVEN DURABILITY

Machined from 6061 aluminum for outstanding, repeatable performance.

INDUSTRY-LEADING RESEARCH, DESIGN & TESTING

We are engineers at heart, like our founder, Glyn Bindon. Therefore, we are bound by a commitment to seek innovative aiming solutions that constantly redefine “brilliant.” This legacy of innovation is fed by what we call The Science of Brilliant®.

LEARN MORE ABOUT THE SCIENCE OF BRILLIANT®

TESTING PROCEDURES INCLUDE:

Solid Zero Tested Vibration Tested Drop Tested
Weight
8.07 oz. (228.78g)
Tube Size
30mm
Length
4.7 in (119.38mm)
Width
2.07 in (52.58mm)
Height Above Rail (in/mm)
1.125" in. (28.58mm)
Feature
Trijicon Q-LOC™ Technology

Trijicon Q-LOC™ Technology Spec Sheet

Download Trijicon Q-LOC™ Technology Spec Sheet DOWNLOAD

Trijicon Q-LOC™ Technology Mounting Instructions

Download Trijicon Q-LOC™ Technology Mounting Instructions DOWNLOAD
